APC Power-Saving Back-UPS ES 8 Outlet
$235.00
Features a resettable circuit breaker Instead of a hard to find fuse, there is a push-button circuit breaker for easy recovery from an overload or short circuit.
Easy to use, this unit includes audible alarms, pro-actively notifying you of changing UPS and utility power conditions.
Description
APC Power-Saving Back-UPS ES 8 Outlet protects your home or office equipment from lightning, surges and spikes – and its even guaranteed!
Features a resettable circuit breaker instead of a hard to find fuse, there is a push-button circuit breaker for easy recovery from an overload or short circuit. Easy to use, this unit includes audible alarms, pro-actively notifying you of changing UPS and utility power conditions.
Automatic self-test means that the battery periodically self-tests ensures early detection of a battery that needs to be replaced.
Transformer Block Spacing Designed to allow the use of up to two transformer block plugs without blocking access to other receptacles.
Features
- Battery failure notification – Provides early-warning fault analysis on batteries enabling timely preventive maintenance
- Data-line Protection – Protection of data lines (Ethernet, Coaxial and Phone lines) ensures complete protection of your equipment from surges. It is very important to protect your equipment from “back door” surges traveling through data lines, as they can be as damaging to your equipment as surges traveling over power lines.
- Battery-protected and surge-only outlets – Reserves power capacity and run time for connected equipment that require battery back-up while providing surge only protection for less critical equipment
- Cold-start capable – Provides temporary battery power when the utility power is out.
- Hot-swappable batteries – Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
- Automatic self-test – Periodic battery self-test ensures early detection of a battery that needs to be replaced.
- Adjustable voltage sensitivity – Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
- Audible alarms – Provides notification of changing utility power and UPS conditions
- User-replaceable batteries – Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
- USB connectivity Provides management of the UPS via a USB port (not available on all models).
- Safety-agency approved Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
- Battery replacement without tools Allows quick, easy battery replacement.
Additional information
| Weight | 7 kg |
|---|---|
| XML Feed Description | Features a resettable circuit breaker Instead of a hard to find fuse, there is a push-button circuit breaker for easy recovery from an overload or short circuit. |
| Specifications | OutputOutput Power Capacity 330 Watts / 550 VANominal Output Voltage 230VOutput Frequency (sync to mains) 47 – 63 HzOther Output Voltages 220Waveform Type Stepped approximation to a sinewaveOutput Connections(4) Australian (Battery Backup) (4) Australian (Surge Protection) Output Voltage Tolerance +/- 5% static and 100% load stepInputNominal Input Voltage 230VInput Frequency 50/60 Hz +/- 5 Hz (auto sensing)Input ConnectionsAustralian/Chinese Cord Length 1.83 metersMaximum Input Current 10ABatteries & RuntimeBattery Type Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproofTypical recharge time 16 hour(s)Replacement Battery APCRBC110Communications & ManagementControl panel LED status display with On Line : On Battery : Replace Battery and Overload indicatorsSurge Protection and FilteringSurge energy rating 310 JoulesFiltering Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449Data Line Protection Analog phone line for phone/fax/modem/DSL (RJ-45 connector), Network line – 10/100 Base-T Ethernet (RJ-45 connector)PhysicalMaximum Height 88.00 mmMaximum Width 180.00 mmMaximum Depth 302.00 mmNet Weight 5.50 KGShipping Weight 6.20 KGShipping Height 128.00 mmShipping Width 235.00 mmShipping Depth 393.00 mmMaster Carton Units 2.00Master Carton Weight 13.00 KGColor BlackEnvironmentalOperating Environment 0 – 40 °COperating Relative Humidity 0 – 95%Operating Elevation 0-9000 metersStorage Temperature -15 – 40 °CStorage Relative Humidity 0 – 95%Storage Elevation 0-9000 metersAudible noise at 1 meter from surface of unit 40.00 dBAConformanceRegulatory Approvals A-tick, C-tick, CE, TelepermitStandard Warranty 2 years repair or replaceSustainable Offer StatusRoHS CompliantREACH REACH: Contains No SVHCsPEP Available in Documentation tabEOLI Available in Documentation tab**The time to recharge to 90% of full battery capacity following a discharge to shutdown using a load rated for 1/2 the full load rating of the UPS. |
